GDM15 series molded case circuit breaker is suitable for AC 50Hz, rated working voltage 380V and below, rated current ranges from 6A up to 100A. Type 01 is generally used for power distribution, to distribute power and protect lines and power equipment from overload and short circuit in the distribution network. Type 02 circuit breaker can also be used as protection motors. The transparent molded case circuit breaker has a visual switch state with visible breakpoints and can also be used as an isolating switch.

Comply with the IEC60947-2、GB/T 14048.2 Standard

Frame Size：40、100

Current Grade：6-40A、10-100A

Shor Circuit Breaking Capacity：Icu=0.3、0.5 kA

Poles：3、4
